PM2.5 HCHO CO2 Detecting Zigbee Air Quality Sensor Tuya Smart Life

Product Categories
SHENZHEN MULTI IR TECHNOLOGY CO., LTD.
Contact Now

PM2.5 HCHO CO2 Detecting Zigbee Air Quality Sensor Tuya Smart Life

  • 1
  • 2

Brand Name : Multi IR

Model Number : PMT300

Certification : CE,FCC,ROHS

Place of Origin : Shenzhen, China

MOQ : Standard packing 200pcs. OEM packing 2000pcs

Price : Negotiable

Payment Terms : T/T in advance

Supply Ability : 5000pcs/day

Delivery Time : 25 working days

Packaging Details : 96PCS/CTN, Carton size: 500*365*386mm

Product Name : WiFi Air Quality Sensor

Application : PM2.5 HCHO CO2 Detecting

Wifi : 2.4G

Communication Mode : ZIGBEE

Average Power Consumption : 2.5W-3.5W

Dimension : 80.3*80.3*63.5mm

Contact Now

​Tuya WiFi Smart Multi-function Air Quality Monitor PM2.5 HCHO CO2 Temperature/Humidity Tuya Smart Life APP Control

1 Function description

The air quality detector detect indoor air quality and display on its TFT screen, it can detect PM2.5, PM10. PM1.0, CO2, temperature and humidity.It transmits the signal via RS485 protocol.

With light sensor to detect the environmental illumination.

2 Technical parameters

Communication protocol Zigbee
Working Voltage AC 100V-240V
Working current ≤100mA
CO2 detecting range 400~2000 PPM 5%±50PPM
Temperature detecting range -10 ~ 55℃ ±1℃
Humidity detecting range 0 ~ 99%RH ±5%RH
PM1.0/PM2.5 /PM10 detecting range 0 ~ 999 ug/m3
PM1.0/PM2.5 /PM10 accuracy 0~100ug/m³: ±15ug/m³ ＞100ug/m³: ±15%
Air quality level

PM2.5(ug/m³)0~75: Good PM2.5(ug/m³)76~115: Moderate

PM2.5(ug/m³)>115: Bad
Light sensing 1 ~ 999 lux ±30%
Display screen TFT screen, 120°
RS485 default address Press key for 10s
Size 86*86*60mm

PM2.5 HCHO CO2 Detecting Zigbee Air Quality Sensor Tuya Smart Life
